| PartNumber | LP156WH2-TLC2 |
| Marca | LG Display |
| mărimea | 15.6 |
| Aplicație | NBPC |
| Rezoluţie | 1366×768 |
| Compoziţie | LCM |
| Luminozitate | 200 |
| CR | 500:1 |
| Culori | 262K |
| Iluminare de fundal | WLED |
| Interfață | LVDS |
| marca panoului | LG Display |
| model de panou | LP156WH2-TLC2 61 Compatible model |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 15.6 inch |
| rezoluţie | 1366(RGB)×768 , WXGA |
| modul de afișare | TN, Normally White, Transmissive |
| Zonă activă | 344.232×193.536 mm |
| contur | 359.3×209.5×5.5 mm |
| stilul formei | Wedge (PCBA Bent, Depth ≥5.2mm) |
| suprafaţă | Glare (Haze 0%), Hard coating (3H) |
| luminozitatea | 200 cd/m² (Typ.) |
| Raport de contrast | 500:1 (Min.) |
| culorile afișajului | 262K (6-bit) |
| timp de raspuns | 16 (Typ.)(Tr+Td) |
| unghi de vedere | 40/40/10/30 (Min.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | WLEDEmbedded (LED Driver) |
| interfață de semnal | LVDS (1 ch, 6-bit), 40 pins |
| tensiune de intrare | 3.3V (Typ.) |
| aplicarea | NBPC |
| LP156WD1-TLB2 | LG Display | 15.6 | 1600×900 |
| LP156WD1-TLD3 | LG Display | 15.6 | 1600×900 |
| LP156WF4-SLB2 | LG Display | 15.6 | 1920×1080 |
| LP156WF4-SLC1 | LG Display | 15.6 | 1920×1080 |
| LP156WF4-SPC1 | LG Display | 15.6 | 1920×1080 |
| LP156WF6-SPK1 | LG Display | 15.6 | 1920×1080 |
| LP156WH1-TLC2 | LG Display | 15.6 | 1366×768 |
| LP156WH2-TLB1 | LG Display | 15.6 | 1366×768 |
| LP156WH3-TLA1 | LG Display | 15.6 | 1366×768 |
| LP156WH3-TLT2 | LG Display | 15.6 | 1366×768 |
| B156RW01 V1 | AUO | 15.6 | 1600×900 |
| LP133X7-H2CC | LG Display | 13.3 | 1024×768 |
| LP140WH1-TLD2 | LG Display | 14.0 | 1366×768 |
| LP141WX1-TLE3 | LG Display | 14.1 | 1280×800 |
| LP171WX2-TLB2 | LG Display | 17.1 | 1440×900 |
| LTD131EQ2X | TOSHIBA | 13.1 | 1600×900 |
| LTM11C307S | TOSHIBA | 11.3 | 1024×768 |
| LTM15C460F | TOSHIBA | 15.0 | 1024×768 |
| LTN140KT03 | Samsung | 14.0 | 1600×900 |
| LTN154AT09-101 | Samsung | 15.4 | 1280×800 |
