| PartNumber | LM270WF7-SLD1 |
| Marca | LG Display |
| mărimea | 27.0 |
| Aplicație | Desktop Monitor Indu |
| Rezoluţie | 1920×1080 |
| Compoziţie | LCM , a-Si TFT-LCD |
| Luminozitate | |
| CR | 1000:1 |
| Culori | 16.7M |
| Iluminare de fundal | WLED |
| Interfață | LVDS |
| producător | LG Display |
| numele modelului | LM270WF7-SLD1 |
| marimea ecranului | 27.0 inch |
| tipul de ecran | LCM , a-Si TFT-LCD |
| numărul de pixeli | 1920(RGB)×1080 (FHD) 81PPI |
| aranjament | RGB Vertical Stripe |
| zona activa (mm) | 597.888 × 336.312 (H×V) |
| contur (mm) | 611.5 × 355.8 (H×V×D) |
| zona rama (mm) | 601.5 × 339.95 (H×V) |
| tratament | Antiglare (Haze 25%), Hard coating (3H) |
| luminanţă | 300 cd/m² (Typ.) |
| Raport de contrast | 1000 : 1 (Typ.) (TM) |
| unghi de vedere | 89/89/89/89 (Typ.)(CR≥10) |
| raspuns | 14 (Typ.)(G to G) ms |
| vedere buna la | Symmetry |
| modul de lucru | IPS, Normally Black, Transmissive |
| adâncimea culorii | 16.7M 72% NTSC |
| lumina de fundal | WLED , 30K hours , No Driver |
| masa | 2.87/3.01Kgs (Typ./Max.) |
| folosit pentru | Desktop Monitor Industrial |
| rată de reîmprospătare | 60Hz |
| touch screen | Without |
| tipul semnalului | LVDS (2 ch, 8-bit) , 30 pins Connector |
| alimentare cu tensiune | 5.0V (Typ.) |
| max. evaluări | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| LM270WF1-TLA1 | LG Display | 27.0 | 1920×1080 |
| LM270WF1-TLD1 | LG Display | 27.0 | 1920×1080 |
| LM270WF3-TLA1 | LG Display | 27.0 | 1920×1080 |
| LM270WF5-SLB1 | LG Display | 27.0 | 1920×1080 |
| LM270WF5-SLN2 | LG Display | 27.0 | 1920×1080 |
| LM270WF5-SSC1 | LG Display | 27.0 | 1920×1080 |
| LM270WF6-SSZ1 | LG Display | 27.0 | 1920×1080 |
| LM270WF7-SSB1 | LG Display | 27.0 | 1920×1080 |
| LM270WQ1-SDF1 | LG Display | 27.0 | 2560×1440 |
| LM270WQ1-SLB1 | LG Display | 27.0 | 2560×1440 |
