| PartNumber | LM156LFCL01 |
| Marca | PANDA |
| mărimea | 15.6 |
| Aplicație | Laptop |
| Rezoluţie | 1920×1080 |
| Compoziţie | Oxide TFT-LCD, LCM |
| Luminozitate | |
| CR | 1000:1 |
| Culori | 262K |
| Iluminare de fundal | WLED |
| Interfață | eDP |
| marca | PANDA |
| model | LM156LFCL01 |
| dimensiunea diagonalei | 15.6 inch |
| tip | Oxide TFT-LCD, LCM |
| format de pixeli | 1920(RGB)×1080 [FHD] 141PPI |
| configurație | RGB Vertical Stripe |
| Zonă activă | 344.16(H)×193.59(V) mm |
| contur dim. | 350.66(H)×216.69(V) ×3.2(D) mm |
| zona rama | - |
| tratament | Hard coating (3H) |
| luminanţă | 220 cd/m² (Typ.) |
| Raport de contrast | 1000:1 (Typ.) (TM) |
| direcția vizualizării | Symmetry |
| timp de raspuns | 25 (Typ.)(Tr+Td) |
| unghi de vedere | 85/85/85/85 (Typ.)(CR≥10) |
| mod de operare | FFS, Normally Black, Transmissive |
| culoare suport | 262K 45% NTSC |
| sursă de lumină | WLED , 15K hours , With LED Driver |
| stilul formei | Slim (PCBA Flat, T≤3.2mm) |
| proiectat pentru | Laptop |
| rata de cadre | 60Hz |
| panou tactil | Without |
| tipul de interfață | eDP (2 Lanes) , eDP1.2 , HBR1 (2.7G/lane) , 30 pins Connector |
| alimentare electrică | 3.3V (Typ.) |
| mediu inconjurator | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
