| PartNumber | LK315T3LA61 |
| Marca | SHARP |
| mărimea | 31.5 |
| Aplicație | LCTV |
| Rezoluţie | 1366×768 |
| Compoziţie | LCM |
| Luminozitate | 500 |
| CR | 3000:1 |
| Culori | 16.7M |
| Iluminare de fundal | CCFL |
| Interfață | LVDS |
| marca panoului | SHARP |
| model de panou | LK315T3LA61 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 31.5 inch |
| rezoluţie | 1366(RGB)×768 , WXGA |
| modul de afișare | ASV, Normally Black, Transmissive |
| Zonă activă | 697.685×392.256 mm |
| contur | 760×450×50 mm |
| suprafaţă | Antiglare (Haze 8%), Hard coating (3H) |
| luminozitatea | 500 cd/m² (Typ.) |
| Raport de contrast | 3000:1 (Typ.) |
| culorile afișajului | 16.7M (8-bit), CIE193172% |
| timp de raspuns | 4 (Typ.)(G to G) |
| unghi de vedere | 88/88/88/88 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | 10 pcsCCFLEmbedded (Inverter) |
| interfață de semnal | LVDS (2 ch, 8-bit), 51 pins |
| tensiune de intrare | 12.0V (Typ.) |
| aplicarea | LCTV |
| BRS315H2 | 31.5 | 1920×1080 | |
| LC320DXN-SER1 | LG Display | 31.5 | 1366×768 |
| LC320EUF-FEP1 | LG Display | 31.5 | 1920×1080 |
| LC320WUD-SCA1 | LG Display | 31.5 | 1920×1080 |
| LK315D3HA9K | SHARP | 31.5 | 1920×1080 |
| LK315D3LA4S | SHARP | 31.5 | 1920×1080 |
| LK315T3LA57 | SHARP | 31.5 | 1366×768 |
| LK315T3LA61 | SHARP | 31.5 | 1366×768 |
| ST3151A04-2 | CSOT | 31.5 | 1366×768 |
| T315HW05 V1 | AUO | 31.5 | 1920×1080 |
| LC370EUN-SDF1 | LG Display | 37 | 1920×1080 |
| LC420WUE-SCA2 | LG Display | 42 | 1920×1080 |
| LC550EUF-PGF1 | LG Display | 55 | 1920×1080 |
| LTA260AP02 | Samsung | 26.0 | 1366×768 |
| LTA320AP33 | Samsung | 31.5 | 1366×768 |
| LTA520HE05 | Samsung | 52 | 1920×1080 |
| T260XW02 VP | AUO | 26.0 | 1366×768 |
| T460HW03 VB | AUO | 46 | 1920×1080 |
| T650HVN04.1 | AUO | 65 | 1920×1080 |
| V400HJ6-LE8 | Innolux | 40 | 1920×1080 |
