| PartNumber | LD420WUN-SCA1 |
| Marca | LG Display |
| mărimea | 42 |
| Aplicație | PID |
| Rezoluţie | 1920×1080 |
| Compoziţie | LCM |
| Luminozitate | 500 |
| CR | 1300:1 |
| Culori | 16.7M/1.06B |
| Iluminare de fundal | EEFL |
| Interfață | LVDS |
| marca panoului | LG Display |
| model de panou | LD420WUN-SCA1 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 42 inch |
| rezoluţie | 1920(RGB)×1080 , FHD |
| modul de afișare | S-IPS, Normally Black, Transmissive |
| Zonă activă | 930.24×523.26 mm |
| contur | 983×576 mm |
| suprafaţă | Antiglare (Haze 10%), Hard coating (3H) |
| luminozitatea | 500 cd/m² (Typ.) |
| Raport de contrast | 1300:1 (Typ.) |
| culorile afișajului | 16.7M/1.06B (8-bit / 8-bit + Dithering), CIE193172% |
| timp de raspuns | 10 (Typ.)(G to G) |
| unghi de vedere | 89/89/89/89 (Min.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | EEFLEmbedded (Inverter) |
| interfață de semnal | LVDS (2 ch, 8/10-bit), 51 pins |
| tensiune de intrare | 12.0V (Typ.) |
| aplicarea | PID |
| LC420EUG-PEF1 | LG Display | 42 | 1920×1080 |
| LD420WUB-SBA1 | LG Display | 42 | 1920×1080 |
| LD420WUB-SBG1 | LG Display | 42 | 1920×1080 |
| LD420WUB-SCA1 | LG Display | 42 | 1920×1080 |
| LD420WUB-SCB1 | LG Display | 42 | 1920×1080 |
| LD420WUB-SCC1 | LG Display | 42 | 1920×1080 |
| LD420WUB-SCG1 | LG Display | 42 | 1920×1080 |
| LD420WUN-SCA1 | LG Display | 42 | 1920×1080 |
| LD420WXN-SAA1 | LG Display | 42 | 1366×768 |
| V420H2-LE3 | Innolux | 42 | 1920×1080 |
| LD470EUD-SDA1 | LG Display | 47 | 1920×1080 |
| LK460D3LA8S | SHARP | 46 | 1920×1080 |
| LK645D3LZ2U | SHARP | 65 | 1080×1920 |
| LTI320AP02 | Samsung | 31.5 | 1366×768 |
| LTI820HD03 | Samsung | 82 | 1920×1080 |
| P460HW02 V0 | AUO | 46 | 1920×1080 |
| P650HVN01.0 | AUO | 65 | 1920×1080 |
| P650HVN02.2 | AUO | 65 | 1920×1080 |
| P650HVN02.6 | AUO | 65 | 1920×1080 |
| RX415TXP01 | ROGIN | 41.5 | 1920×540 |
