| PartNumber | LC470DUT-SEF2 |
| Marca | LG Display |
| mărimea | 47 |
| Aplicație | LCTV |
| Rezoluţie | 1920×1080 |
| Compoziţie | CELL |
| Luminozitate | 0 |
| CR | 1300:1 |
| Culori | 16.7M |
| Iluminare de fundal | No B/L |
| Interfață | Mini LVDS |
| marca panoului | LG Display |
| model de panou | LC470DUT-SEF2 |
| tip panou | a-Si TFT-LCD , CELL |
| dimensiunea panoului | 47 inch |
| rezoluţie | 1920(RGB)×1080 , FHD |
| modul de afișare | IPS, Normally Black, Transmissive |
| Zonă activă | 1039.68×584.82 mm |
| contur | 1046.68×594.02 mm |
| suprafaţă | Hard coating (2H), Reflection 2.0% (Max.) |
| adâncimea sticlei | 0.50+0.50 mm |
| transmisivitatea | 4.5% (Typ.)(with Polarizer) |
| Raport de contrast | 1300:1 (Typ.) |
| culorile afișajului | 16.7M (8-bit) |
| timp de raspuns | 4/4 (Typ.)(Tr/Td) |
| unghi de vedere | 89/89/89/89 (MIn.)(CR≥10)(L/R/U/D) |
| frecvență | 240Hz |
| interfață de semnal | Mini LVDS, 160 pins |
| tensiune de intrare | 12.0V (Typ.)(VLCD) |
| aplicarea | LCTV |
