| PartNumber | KCG057QV1DL-G770 |
| Marca | Kyocera |
| mărimea | 5.7 |
| Aplicație | Industrial |
| Rezoluţie | 320×240 |
| Compoziţie | CSTN-LCD, LCM |
| Luminozitate | |
| CR | 55:1 |
| Culori | Color |
| Iluminare de fundal | CCFL |
| Interfață | Parallel |
| marca | Kyocera |
| model | KCG057QV1DL-G770 |
| dimensiunea diagonalei | 5.7 inch |
| tip | CSTN-LCD, LCM |
| format de pixeli | 320(RGB)×240 [QVGA] 70PPI |
| configurație | RGB Vertical Stripe |
| Zonă activă | 115.2(H)×86.4(V) mm |
| contur dim. | 144(H)×104.8(V) ×15.3(D) mm |
| zona rama | 119.4(H)×90.6(V) mm |
| tratament | Hard coating (2H) |
| luminanţă | - |
| Raport de contrast | 55:1 (Typ.) (TM) |
| direcția vizualizării | - |
| timp de raspuns | 180/170 (Typ.)(Tr/Td) |
| unghi de vedere | 50/50/20/35 (Typ.)(CR≥2) |
| mod de operare | STN, Normally Black, Transmissive |
| culoare suport | Color |
| sursă de lumină | CCFL [1 pcs] |
| greutate | 220g (Typ.) |
| proiectat pentru | Industrial |
| rata de cadre | 75Hz |
| panou tactil | 4-wire Resistive Touch |
| tipul de interfață | Parallel Data (1ch, 8-bit) Connector |
| alimentare electrică | 3.3/5.0V (Typ.)(VDD) |
| mediu inconjurator | Operating Temperature: 0 ~ 60 °C ; Storage Temperature: -20 ~ 60 °C |
