| PartNumber | HV320WHB-N80 |
| Marca | BOE |
| mărimea | 31.5 |
| Aplicație | LCTV |
| Rezoluţie | 1366×768 |
| Compoziţie | CELL |
| Luminozitate | 0 |
| CR | 1200:1 |
| Culori | 16.7M |
| Iluminare de fundal | No B/L |
| Interfață | LVDS |
| marca panoului | BOE |
| model de panou | HV320WHB-N80 |
| tip panou | a-Si TFT-LCD , CELL |
| dimensiunea panoului | 31.5 inch |
| rezoluţie | 1366(RGB)×768 , WXGA |
| modul de afișare | ADS, Normally Black, Transmissive |
| Zonă activă | 697.685×392.256 mm |
| contur | 715×411 mm |
| suprafaţă | Antiglare (Haze 1%), Hard coating (3H) |
| transmisivitatea | 6.2% (Typ.)(with Polarizer) |
| Raport de contrast | 1200:1 (Typ.) |
| culorile afișajului | 16.7M (8-bit) |
| timp de raspuns | 8 (Typ.)(G to G) |
| unghi de vedere | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| interfață de semnal | LVDS (1 ch, 8-bit), 30 pins |
| tensiune de intrare | 12.0V (Typ.) |
| aplicarea | LCTV |
| HV320WHB-N00 | BOE | 31.5 | 1366×768 |
| HV320WHB-N06 | BOE | 31.5 | 1366×768 |
| HV320WHB-N80 | BOE | 31.5 | 1366×768 |
| HV320WX2-200 | BOE | 31.5 | 1366×768 |
| HV320WX2-201 | BOE | 31.5 | 1366×768 |
| HV320WX2-206 | BOE | 31.5 | 1366×768 |
| HV320WX2-500 | BOE | 31.5 | 1366×768 |
| HV320WXC-100 | BOE | 31.5 | 1366×768 |
| HV320WXC-201 | BOE | 31.5 | 1366×768 |
| LTF320AP06 | Samsung | 31.5 | 1366×768 |
| HV320WX2-201 | BOE | 31.5 | 1366×768 |
| LC320EXN-SEA2 | LG Display | 31.5 | 1366×768 |
| LC320EXN-SEA3 | LG Display | 31.5 | 1366×768 |
| LC320WXN-SBA1 | LG Display | 31.5 | 1366×768 |
| LC420EUD-SDF1 | LG Display | 42 | 1920×1080 |
| LC470EUG-PFF1 | LG Display | 47 | 1920×1080 |
| LC470EUN-SFF2 | LG Display | 47 | 1920×1080 |
| V236BJ1-P01 Rev.C3 | Innolux | 23.6 | 1366×768 |
| V260B3-LE1 | Innolux | 26.0 | 1366×768 |
| V370B1-L03 | Innolux | 37 | 1366×768 |
