| PartNumber | G075ADE-T01 |
| Marca | Innolux |
| mărimea | 7.5 |
| Aplicație | NBPC |
| Rezoluţie | 1200×900 |
| Compoziţie | LCM |
| Luminozitate | 120 |
| CR | 85:1 |
| Culori | 262K |
| Iluminare de fundal | WLED |
| Interfață | TTL |
| marca panoului | INNOLUX |
| model de panou | G075ADE-T01 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 7.5 inch |
| rezoluţie | 1200×900 |
| modul de afișare | TN, Normally White, Transflective |
| Zonă activă | 152.4×114.3 mm |
| contur | 169.7×139.7×6.5 mm |
| suprafaţă | Antiglare (Haze 25%), Hard coating (3H) |
| luminozitatea | 120 cd/m² (Typ.) |
| Raport de contrast | 85:1 (Typ.)(Transmissive)4:1 (Typ.)(Reflective) |
| culorile afișajului | 262K (6-bit), CIE193129% |
| timp de raspuns | 30/20 (Typ.)(Tr/Td) |
| unghi de vedere | 15/15/15/15 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | 4S3PWLEDWithout Driver |
| interfață de semnal | TTL (1 ch, 6-bit), 55 pins |
| tensiune de intrare | 1.8/9.6/18/-7V (Typ.)(VDD/VAA/VGH/VGL) |
| aplicarea | NBPC |
