| PartNumber | CC580PV6D |
| Marca | PANDA |
| mărimea | 58 |
| Aplicație | TV Sets |
| Rezoluţie | 3840×2160 |
| Compoziţie | CELL , Oxide TFT-L |
| Luminozitate | |
| CR | 6000:1 |
| Culori | 1.07B |
| Iluminare de fundal | No |
| Interfață | |
| producător | PANDA |
| numele modelului | CC580PV6D |
| marimea ecranului | 58 inch |
| tipul de ecran | CELL , Oxide TFT-LCD |
| numărul de pixeli | 3840(RGB)×2160 (UHD) 76PPI |
| aranjament | RGB Vertical Stripe |
| zona activa (mm) | 1270.08 × 721.44 (H×V) |
| contur (mm) | 1280.08 × 732.94 × 1.36 (H×V×D) |
| zona rama (mm) | - |
| tratament | Antiglare (Haze 2.3%), Hard coating (3H) |
| luminanţă | 0 cd/m² |
| Raport de contrast | 6000 : 1 (Typ.) (TM) |
| unghi de vedere | 89/89/89/89 (Typ.)(CR≥10) |
| raspuns | 8 (Typ.)(G to G) ms |
| vedere buna la | Symmetry |
| modul de lucru | UV2A, Normally Black, Transmissive |
| grosimea sticlei | 0.50+0.50 mm |
| transmisivitatea | 5.3% (Typ.)(with Polarizer) |
| adâncimea culorii | 1.07B 71% NTSC |
| lumina de fundal | No B/L |
| masa | 2.78Kgs (Typ.) |
| folosit pentru | TV Sets |
| rată de reîmprospătare | 60Hz |
| touch screen | Without |
| lista de drivere ic | Built-in COF 12 source chips |
| max. evaluări | Storage Temp.: -20 ~ 65 °C Operating Temp.: 0 ~ 50 °C |
| LK580Z3LA13 | SHARP | 58 | 2560×1080 |
| V580DK1-KS2 | Innolux | 58 | 3840×2160 |
| V580DK1-LS1 | Innolux | 58 | 3840×2160 |
| V580DK1-QS2 | Innolux | 58 | 3840×2160 |
| V580DK2-KS1 | Innolux | 58 | 3840×2160 |
| V580DK2-KS1 Rev.C8 | Innolux | 58 | 3840×2160 |
| V580DK2-LD1 | Innolux | 58 | 3840×2160 |
| V580DK2-QS1 | Innolux | 58 | 3840×2160 |
| V580HJ1-PD6 | Innolux | 58 | 1920×1080 |
| V580HK1-LD6 | Innolux | 58 | 1920×1080 |
