| PartNumber | B173RW01 V3 |
| Marca | AUO |
| mărimea | 17.3 |
| Aplicație | NBPC |
| Rezoluţie | 1600×900 |
| Compoziţie | LCM |
| Luminozitate | 220 |
| CR | 500:1 |
| Culori | 262K |
| Iluminare de fundal | WLED |
| Interfață | LVDS |
| marca panoului | AUO |
| model de panou | B173RW01 V3 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 17.3 inch |
| rezoluţie | 1600(RGB)×900 , HD+ |
| modul de afișare | TN, Normally White, Transmissive |
| Zonă activă | 382.08×214.92 mm |
| contur | 398.1×232.8×5.8 mm |
| stilul formei | Wedge (PCBA Bent, Depth ≥5.2mm) |
| suprafaţă | Glare (Haze 0%) |
| luminozitatea | 220 cd/m² (Typ.) |
| Raport de contrast | 500:1 (Typ.) |
| culorile afișajului | 262K (6-bit), CIE193160% |
| timp de raspuns | 2/6 (Typ.)(Tr/Td) |
| unghi de vedere | 45/45/15/35 (Min.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | WLEDEmbedded (LED Driver) |
| interfață de semnal | LVDS (2 ch, 6-bit), 40 pins |
| tensiune de intrare | 3.3V (Typ.) |
| aplicarea | NBPC |
| B173RW01 V0 | AUO | 17.3 | 1600×900 |
| B173RW01 V1 | AUO | 17.3 | 1600×900 |
| B173RW01 V2 HW7A | AUO | 17.3 | 1600×900 |
| B173RW01 V3 | AUO | 17.3 | 1600×900 |
| B173RW01 V5 | AUO | 17.3 | 1600×900 |
| LP173WD1-TLC1 | LG Display | 17.3 | 1600×900 |
| LP173WD1-TLC2 | LG Display | 17.3 | 1600×900 |
| LTN173HT02-D02 | Samsung | 17.3 | 1920×1080 |
| LTN173KT02-W01 | Samsung | 17.3 | 1600×900 |
| N173FGE-E23 | Innolux | 17.3 | 1600×900 |
| B156XW02 V6 | AUO | 15.6 | 1366×768 |
| HT140WXB-100 | BOE | 14.0 | 1366×768 |
| LP140WH2-TLM1 | LG Display | 14.0 | 1366×768 |
| LP154W02-B1K2 | LG Display | 15.4 | 1680×1050 |
| LQ156D1JX03 | SHARP | 15.6 | 3840×2160 |
| LTN121AT01-002 | Samsung | 12.1 | 1280×800 |
| LTN141AT03-301 | Samsung | 14.1 | 1280×800 |
| LTN150XB-L02 | Samsung | 15.0 | 1024×768 |
| LTN156KT01-W01 | Samsung | 15.6 | 1600×900 |
| N184H4-L04 | Innolux | 18.4 | 1920×1080 |
