| PartNumber | B140XW02 V2 |
| Marca | AUO |
| mărimea | 14.0 |
| Aplicație | NBPC |
| Rezoluţie | 1366×768 |
| Compoziţie | LCM |
| Luminozitate | 200 |
| CR | 500:1 |
| Culori | 262K |
| Iluminare de fundal | WLED |
| Interfață | LVDS |
| marca panoului | AUO |
| model de panou | B140XW02 V2 8 Compatible model |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 14.0 inch |
| rezoluţie | 1366(RGB)×768 , WXGA |
| modul de afișare | TN, Normally White, Transmissive |
| Zonă activă | 309.399×173.952 mm |
| contur | 320.4×205.1×3.6 mm |
| stilul formei | Flat (PCBA Flat, Depth 3.4~4.0mm) |
| suprafaţă | Glare (Haze 0%), Hard coating (3H) |
| luminozitatea | 200 cd/m² (Typ.) |
| Raport de contrast | 500:1 (Typ.) |
| culorile afișajului | 262K (6-bit), CIE193145% |
| timp de raspuns | 2/6 (Typ.)(Tr/Td) |
| unghi de vedere | 45/45/15/35 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | WLEDEmbedded (LED Driver) |
| interfață de semnal | LVDS (1 ch, 6-bit), 40 pins |
| tensiune de intrare | 3.3V (Typ.) |
| aplicarea | NBPC |
| B140XTN02.3 | AUO | 14.0 | 1366×768 |
| B140XTN03.1 | AUO | 14.0 | 1366×768 |
| B140XTN03.2 | AUO | 14.0 | 1366×768 |
| B140XTN03.5 | AUO | 14.0 | 1366×768 |
| B140XTN03.9 | AUO | 14.0 | 1366×768 |
| B140XW01 V8 | AUO | 14.0 | 1366×768 |
| B140XW01 V9 | AUO | 14.0 | 1366×768 |
| B140XW02 V0 | AUO | 14.0 | 1366×768 |
| B140XW02 V2 | AUO | 14.0 | 1366×768 |
| B140XW03 V0 | AUO | 14.0 | 1366×768 |
| B140XW01 V4 | AUO | 14.0 | 1366×768 |
| B156XTN04.5 | AUO | 15.6 | 1366×768 |
| BT156GW01 V.3 | Innolux | 15.6 | 1366×768 |
| HB140WX1-401 | BOE | 14.0 | 1366×768 |
| LP156WH2-TLRA | LG Display | 15.6 | 1366×768 |
| LP164WD1-TLA1 | LG Display | 16.4 | 1600×900 |
| LQ106K1LA05 | SHARP | 10.6 | 1280×768 |
| LTD121EWPF | TOSHIBA | 12.1 | 1280×800 |
| LTN154AT09-102 | Samsung | 15.4 | 1280×800 |
| NL10276BC28-21A | NLT | 14.1 | 1024×768 |
