| PartNumber | AT102TN42 |
| Marca | Innolux |
| mărimea | 10.2 |
| Aplicație | NOPC |
| Rezoluţie | 1024×600 |
| Compoziţie | LCM |
| Luminozitate | 200 |
| CR | 500:1 |
| Culori | 262K/16.2M |
| Iluminare de fundal | WLED |
| Interfață | LVDS |
| marca panoului | INNOLUX |
| model de panou | AT102TN42 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 10.2 inch |
| rezoluţie | 1024(RGB)×600 , WSVGA |
| modul de afișare | TN, Normally White, Transmissive |
| Zonă activă | 221.798×131.52 mm |
| contur | 235×145.8×5.45 mm |
| suprafaţă | Clear |
| luminozitatea | 200 cd/m² (Typ.) |
| Raport de contrast | 500:1 (Typ.) |
| culorile afișajului | 262K/16.2M (6-bit / 6-bit + Dithering) |
| timp de raspuns | 10/15 (Typ.)(Tr/Td) |
| unghi de vedere | 80/80/70/80 (Typ.)(CR≥10)(L/R/U/D) |
| tip lampa | WLEDEmbedded (LED Driver) |
| interfață de semnal | LVDS (1 ch, 6/8-bit), 30 pins |
| tensiune de intrare | 3.3V (Typ.) |
| rohs: | |
| aplicarea | NOPC |
