| PartNumber | AA057VG12 |
| Marca | Mitsubishi |
| mărimea | 5.7 |
| Aplicație | IA |
| Rezoluţie | 640×480 |
| Compoziţie | LCM |
| Luminozitate | 500 |
| CR | 185:1 |
| Culori | 262K |
| Iluminare de fundal | WLED |
| Interfață | TTL |
| marca panoului | Mitsubishi |
| model de panou | AA057VG12 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 5.7 inch |
| rezoluţie | 640(RGB)×480 , VGA |
| modul de afișare | TN, Normally White, Transflective |
| Zonă activă | 115.2×86.4 mm |
| contur | 135×104.6×8.85 mm |
| suprafaţă | Hard coating (2H), Antireflection |
| luminozitatea | 500 cd/m² (Typ.) |
| Raport de contrast | 185:1 (Typ.)(Transmissive) |
| culorile afișajului | 262K (6-bit), CIE193140% |
| timp de raspuns | 4/16 (Typ.)(Tr/Td) |
| unghi de vedere | 80/80/50/65 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | WLEDEmbedded (LED Driver) |
| interfață de semnal | CMOS (1 ch, 6-bit), 33 pins |
| tensiune de intrare | 3.3V (Typ.) |
| aplicarea | IA |
| AA050ME01 | Mitsubishi | 5.0 | 800×480 |
| AA050ME01--T1 | Mitsubishi | 5.0 | 800×480 |
| AA050MG01 | Mitsubishi | 5.0 | 800×480 |
| AA057QD01 | Mitsubishi | 5.7 | 320×240 |
| AA057VF12 | Mitsubishi | 5.7 | 640×480 |
| AA057VG02 | Mitsubishi | 5.7 | 640×480 |
| AA057VG12 | Mitsubishi | 5.7 | 640×480 |
| EL320.240.36 IN | Lumineq | 5.7 | 320×240 |
| LM32004 | SHARP | 5.7 | 320×240 |
| TM057QVHG01 | Tianma | 5.7 | 640×480 |
| AM-800480LTMQW-W0H | AMPIRE | 5.0 | 800×480 |
| ELT256.120.90 | Lumineq | 10.0 | 256×120 |
| HGS128321-B-EH-LV | Other | 2.2 | 128×32 |
| KCS057QV1AJ-G23 | Kyocera | 5.7 | 320×240 |
| LQ104V1DG5B | SHARP | 10.4 | 640×480 |
| NL6448BC26-27 | NLT | 8.4 | 640×480 |
| OEL9M0078-Y-E | Other | 1.45 | 132×16 |
| PM070WL4 | E Ink | 7.0 | 800×480 |
| TX26D202VM0BAA | KOE | 10.1 | 1920×1200 |
| UG-2864HLBEG01 | WiseChip | 0.96 | 128×64 |
