| PartNumber | A190EN02 V0 |
| Marca | AUO |
| mărimea | 19.0 |
| Aplicație | DMPC |
| Rezoluţie | 1280×1024 |
| Compoziţie | LCM |
| Luminozitate | 350 |
| CR | 1000:1 |
| Culori | 16.7M |
| Iluminare de fundal | CCFL |
| Interfață | LVDS |
| marca panoului | AUO |
| model de panou | A190EN02 V0 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 19.0 inch |
| rezoluţie | 1280(RGB)×1024 , SXGA |
| modul de afișare | TN, Normally White, Transmissive |
| Zonă activă | 376.32×301.06 mm |
| contur | 396×324×16.8 mm |
| suprafaţă | Glare (Haze 0%), Hard coating (3H) |
| luminozitatea | 350 cd/m² (Typ.) |
| Raport de contrast | 1000:1 (Typ.) |
| culorile afișajului | 16.7M (6-bit + Hi-FRC) |
| timp de raspuns | 3.6/1.4 (Typ.)(Tr+Td) |
| unghi de vedere | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | 4 pcsCCFLWithout Driver |
| interfață de semnal | LVDS (2 ch, 8-bit), 30 pins |
| tensiune de intrare | 5.0V (Typ.) |
| aplicarea | DMPC |
| A190EN02 V0 | AUO | 19.0 | 1280×1024 |
| G190EG02 V0 | AUO | 19.0 | 1280×1024 |
| HSD190MEN3-A00 | HannStar | 19.0 | 1280×1024 |
| LM190E09-TLD1 | LG Display | 19.0 | 1280×1024 |
| LM190WX1-TLC1 | LG Display | 19.0 | 1440×900 |
| LQ190E1LX75 | SHARP | 19.0 | 1280×1024 |
| LTM190BT03 | Samsung | 19.0 | 1440×900 |
| LTN190W1-L01 | Samsung | 19.0 | 1680×1050 |
| MT190AW01 V.7 | Innolux | 19.0 | 1440×900 |
| MT190AW02 V.4 | Innolux | 19.0 | 1440×900 |
| HT190WG1-100 | BOE | 19.0 | 1440×900 |
| HT215F01-100 | BOE | 21.5 | 1920×1080 |
| LM170E01-A6 | LG Display | 17.0 | 1280×1024 |
| LM200WD3-TLA1 | LG Display | 20.0 | 1600×900 |
| LM230WF3-SSA1 | LG Display | 23.0 | 1920×1080 |
| LM238WF2-SSG2 | LG Display | 23.8 | 1920×1080 |
| LM240WU4-SLB3 | LG Display | 24.0 | 1920×1200 |
| LTM185AT02 | Samsung | 18.5 | 1366×768 |
| M190EG02 V7 | AUO | 19.0 | 1280×1024 |
| M190ETN01.0 | AUO | 19.0 | 1280×1024 |
